JavaScript Mechanics Visualizer

Learn how JavaScript handles primitive values and references (objects and arrays).

Play around by running JS statements, and seeing how the data are structured in the memory.

---

Try these (type or copy into the input box, and press Enter).

• Set x to the number 5 (a primitive value).

x = 5

• Double x by multiplying its current value.

x = x*2

• Double x again using compound assignment.

x *= 2

• Create an array y of three numbers (an object stored by reference).

y = [1, 2, 3]

• Copy the primitive value of x into z (no aliasing for primitives).

z = x

• Copy the reference of array y into u (now u and y alias the same array).

u = y

• Mutate the first element of y to demonstrate mutations are visible through all aliases.

y[0] = 7

• Read the first element via the alias to show shared state.

console.log(u[0])

• Create two separate but identical-looking objects and compare them by reference (not equal).

x = {name: "Johnny", age: 21}
y = {name: "Johnny", age: 21}
console.log(x==y)

• Point x to the same object as y and compare again (equal by reference).

x = y
console.log(x==y)

• Create two distinct user objects and put their references into an array z.

x = {name: "Johnny", age: 21}
y = {name: "Jimmy", age: 61}
z = [x, y]

• Remove the standalone variables; the objects remain reachable via z.

delete x
delete y

• Attempt property access with incorrect syntax, then access the first object's age correctly.

console.log(z[0.age])
console.log(z[0].age)

• Create a nested user object with an address.

user = {name: "Jim", address: {city: "London", street: "Downing Street"}}

• Set the name via the property.

user.name = "Joey"

• Add a roles array and push a new role to show in-place mutation.

user.roles = ["admin"]
user.roles.push("operator")

• Log the number of roles.

console.log(user.roles.length)

• Replace a role by index to mutate an element in-place.

user.roles[1] = "moderator"

• Try the difference between referencing a method and calling it, then pop the last role correctly.

user.roles.pop
user.roles.pop()
